    J.I. Case R

    J.I. Case R tractor photo I&T Manual: Case C, D, L, R, S, V, 200, 300, 450, 400, 500, 600, 700, 800
    I&T Shop Manual
    1936 - 1940






    Production:

    Manufacturer:J.I. Case
    Original price (USD):$892


    Variants:

    R:standard tread
    RC:row-crop
    RO:orchard


    J.I. Case R Engine:

       Waukesha 2.2L 4-cyl gasoline
    full engine details ...


    Capacity:



    Dimensions & Tires:

    Weight:4,150 lbs [1882 kg]
    Front tire:5.00-15
    Rear tire:11.24-24
    full dimensions and tires ...


    R Serial Numbers:

    Location:Plate near instrument panel
    1936: 300901
    1937: 301001
    1938: 4200001
    1939: 4300001
    1940: 4400001

    how to read serial numbers...


    J.I. Case R Power:

    Drawbar (claimed):14 hp [10.4 kW]
    PTO (claimed):18 hp [13.4 kW]
    Drawbar (tested):18.23 hp [13.6 kW]
    Belt (tested):20.52 hp [15.3 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Cab:Open operator station.
