Tractors > Big Bud > 525/50

Big Bud 525/50

Big Bud 525/50 tractor photo
1979 - 1982   3 Series
Four-wheel Drive (4WD) tractor






Production:

Manufacturer:Big Bud
Factory:Havre, Montana, USA


Variants:

525/20:gear shift
525/50:power shift


Big Bud 525/50 Engine:

   Cummins 18.8L 6-cyl diesel
full engine details ...


Capacity:

Fuel:550 gal [2081.8 L]
Hydraulic system:36 gal [136.3 L]


Dimensions & Tires:

Wheelbase:150 inches [381 cm]
Weight:45000 to 52000 pounds
Front tire:30.5-32
Rear tire:30.5-32
full dimensions and tires ...


525/50 Serial Numbers:


- Serial numbers unknown -



Big Bud 525/50 Power:

Engine:525 hp [391.5 kW]
Drawbar (tested):406.48 hp [303.1 kW]
power test details ...


Mechanical:

Chassis:4x4 articulated 4WD
Final drives:planetary
Steering:articulated power
Brakes:pneumatic drum
Cab:Cruiser Cab standard with air-conditioning.


Hydraulics:

Type:closed center
Capacity:36 gal [136.3 L]
Steering flow:36 gpm [136.3 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:75


Battery:

Volts:12
