Nebraska Tractor Test 903: |
| Test Date: | June 11 - 19, 1965
|
| Type: | 6-speed 2WD
|
| Engine: | 186 diesel
|
| PTO power (rated engine speed): | 51.60 hp [38.5 kW]
|
| PTO fuel use (engine speed): | 3.4 gal/hour [12.9 l/hour]
|
| PTO power (rated PTO speed): | 48.49 hp [36.2 kW]
|
| PTO fuel use (PTO speed): | 3.0 gal/hour [11.4 l/hour]
|
| Drawbar power (max): | 43.47 hp [32.4 kW]
|
| Drawbar fuel use (max): | 3.4 gal/hour [12.9 l/hour]
|
| Drawbar pull (max): | 6,039 lbs [2739 kg]
|
| Max pull gear: | 1
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 977: |
| Test Date: | May 27 - June 3, 1968
|
| Type: | 6-speed 2WD
|
| Engine: | 195 diesel
|
| PTO power (rated engine speed): | 52.07 hp [38.8 kW]
|
| PTO fuel use (engine speed): | 3.2 gal/hour [12.1 l/hour]
|
| PTO power (rated PTO speed): | 49.65 hp [37.0 kW]
|
| PTO fuel use (PTO speed): | 3.0 gal/hour [11.4 l/hour]
|
| Drawbar power (max): | 43.31 hp [32.3 kW]
|
| Drawbar fuel use (max): | 3.1 gal/hour [11.7 l/hour]
|
| Drawbar pull (max): | 7,142 lbs [3239 kg]
|
| Max pull gear: | 1-Lo
|
| Test report: | PDF file
|
|
|
| |
Nebraska Tractor Test 1144: |
| Test Date: | September 17 - October 1, 1973
|
| Type: | 12-speed 2WD
|
| Engine: | 195 diesel
|
| PTO power (rated engine speed): | 53.77 hp [40.1 kW]
|
| PTO fuel use (engine speed): | 3.5 gal/hour [13.2 l/hour]
|
| PTO power (rated PTO speed): | 50.48 hp [37.6 kW]
|
| PTO fuel use (PTO speed): | 3.3 gal/hour [12.5 l/hour]
|
| Drawbar power (max): | 45.68 hp [34.1 kW]
|
| Drawbar fuel use (max): | 3.4 gal/hour [12.9 l/hour]
|
| Drawbar pull (max): | 7,335 lbs [3327 kg]
|
| Max pull gear: | HS-1
|
| Test report: | PDF file
|
| |
