| | Production: |
| Manufacturer: | International Harvester
|
| Factory: | -unknown- |
| Total built: | 294 (IH/wheatland)
5,592 (Farmall/row-crop)
|
| Original price: | $12,400 (1971)
|
| | |
| International Harvester 6-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 42 gal [159.0 L]
40 gal [151.4 L] (optional auxiliary tank)
|
| | |
| Rear Type: | 3/2
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 1000
|
| | |
| Wheelbase: | 105 inches [266 cm]
|
| Weight: | 12800 to 17350 pounds
|
| Front tire: | 11L-15
|
| Rear tire: | 18.4-38
|
| full dimensions and tires ... | | | 1456 Serial Numbers: |
| Location: | Clutch housing, right side
|
1969: 1001 (IH)
1970: 10025 (IH)
1971: 10249 (IH)
1969: 10001 (Farmall)
1970: 10405 (Farmall)
1971: 14149 (Farmall)
how to read serial numbers...
|
|
| | International Harvester 1456 Power: |
| PTO (claimed): | 130 hp [96.9 kW]
|
| Drawbar (tested): | 114.69 hp [85.5 kW]
|
| PTO (tested): | 131.1 hp [97.8 kW]
|
| power test details ... | | | Mechanical: |
| Chassis: | 4x2 2WD
4x4 MFWD 4WD optional
|
| Steering: | hydrostatic power
|
| Brakes: | independent hydraulic dry disc
|
| Cab: | Cab optional with heat and A/C
|
|
|
| | Hydraulics: |
| Type: | -unknown- |
| Capacity: | -unknown- |
| Pressure: | -unknown- |
| Valve flow: | 12 gpm [45.4 lpm]
|
| | Electrical: |
| Ground: | -unknown- |
| | Battery: |
| Number: | 2
|
| Cold-cranking amps: | -unknown- |
| Volts: | 6
|
| Amp-hours: | 204
|
