| | Production: |
| Manufacturer: | International Harvester
|
| Factory: | -unknown- |
| Total built: | 21,017
|
| Original price: | $18,000 (1976)
|
| | Variants: |
| Hi-Clear: | high-crop model
|
| | |
| International Harvester 6-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 37 gal [140.0 L]
|
| Hydraulic system: | 22.5 gal [85.2 L]
|
| | Rear Hitch: |
| Type: | IH Fast Hitch
|
| Rear lift: | 5,000 lbs [2268 kg] (at 24 inches)
|
| | |
| Rear Type: | 2
|
| Rear lift (at 24"/610mm): | 4,400 lbs [1995 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 540/1000
|
| | |
| Wheelbase: | 105 inches [266 cm]
|
| Weight: | 11116 to 13500 pounds
|
| Front tire: | 9.5L-15
|
| Rear tire: | 18.4-34
|
| full dimensions and tires ... | | | 966 Serial Numbers: |
| Location: | Clutch housing, left side
|
1971: 7101
1972: 11815
1973: 17794
1974: 22526
1975: 28119
1976: 31772
how to read serial numbers...
|
|
| | International Harvester 966 Power: |
| Engine: | 91 hp [67.9 kW]
|
| Drawbar (claimed): | 84 hp [62.6 kW]
|
| PTO (claimed): | 95 hp [70.8 kW]
|
| Drawbar (tested): | 85.21 hp [63.5 kW]
|
| PTO (tested): | 100.80 hp [75.2 kW]
|
| power test details ... | | | Mechanical: |
| Chassis: | 4x2 2WD
4x4 MFWD 4WD optional
|
| Steering: | Hydrostatic power
|
| Brakes: | Independent hydraulic dry disc
|
| Cab: | Cab optional with heat and A/C
|
|
|
| | Hydraulics: |
| Type: | open
|
| Capacity: | 22.5 gal [85.2 L]
|
| Pressure: | 2000 psi [137.9 bar]
|
| Valves: | 1 to 4
|
| Valve flow: | 12 gpm [45.4 lpm]
|
| Total flow: | 24 gpm [90.8 lpm]
|
| Steering flow: | 9 gpm [34.1 lpm]
|
| Steering press.: | 1550 psi [106.9 bar]
|
| | Electrical: |
| Ground: | -unknown- |
| Alternator amps: | 32
|
| | Battery: |
| Number: | 2
|
| Cold-cranking amps: | -unknown- |
| Volts: | 6
|
| Amp-hours: | 172
|
