    International Harvester 544 - tests

    No photo available
     I&T Manual: IH 544, 656, 666, 686, 684, 784, 884, 1466, 1468, 1486, 1568, 1586, Hydro 70, 84, 86, 100, 186
    I&T Shop Manual for the
    International Harvester 544
    Production years:1968 - 1973
    Tractor type:Farm/Agricultural tractor
    more International Harvester 544 specifications...






    Nebraska Tractor Test 983:

    Test Date:September 1968
    Engine:diesel
    PTO power (rated engine speed):52.95 hp [39.5 kW]
    PTO fuel use (engine speed):3.3 gal/hour [12.5 l/hour]
    Drawbar power (max):44.6 hp [33.3 kW]
    Drawbar fuel use (max):3.3 gal/hour [12.5 l/hour]


    Nebraska Tractor Test 984:

    Test Date:September 1968
    Engine:gasoline
    PTO power (rated engine speed):52.9 hp [39.4 kW]
    PTO fuel use (engine speed):4.4 gal/hour [16.7 l/hour]
    Drawbar power (max):44.7 hp [33.3 kW]
    Drawbar fuel use (max):4.4 gal/hour [16.7 l/hour]


    Nebraska Tractor Test 1007:

    Test Date:April 1969
    Engine:gasoline
    PTO power (rated engine speed):53.9 hp [40.2 kW]
    PTO fuel use (engine speed):5.6 gal/hour [21.2 l/hour]
    Drawbar power (max):40.3 hp [30.1 kW]
    Drawbar fuel use (max):5.5 gal/hour [20.8 l/hour]


    Nebraska Tractor Test 1029:

    Test Date:November 1969
    Type:hydrostatic
    Engine:diesel
    PTO power (rated engine speed):55.5 hp [41.4 kW]
    PTO fuel use (engine speed):4.1 gal/hour [15.5 l/hour]
    Drawbar power (max):42.6 hp [31.8 kW]
    Drawbar fuel use (max):4.3 gal/hour [16.3 l/hour]
