    International Harvester 424

    International Harvester 424 tractor photo  I&T Manual: IH 100, 130, 140, 200, 230, 240, 404, 2404, 330, 340, 504, 2504, B-275, B-414, 354, 364, 384, 424, 444, 2424, 2444
    I&T Shop Manual
    1964 - 1967
    Utility tractor






    Production:

    Manufacturer:International Harvester
    Factory:Doncaster, England
     Louisville, Kentucky, USA
    Original price (USD):$3,300 (1967)


    International Harvester 424 Engines:

       International Harvester 2.4L 4-cyl gasoline
       International Harvester 2.5L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:14 gal [53.0 L]


    3-Point Hitch:

    Rear Type:I


    Power Take-off (PTO):

    Rear PTO:live
    Rear RPMs:540


    Dimensions & Tires:

    Wheelbase:70 inches [177 cm]
    Weight:4,055 lbs [1839 kg]
    Front tire:5.50-16
    Rear tire:12.4-28
    full dimensions and tires ...


    424 Serial Numbers:

    Location:Tractor's clutch housing.
    photo of 424 serial number

    1964: 501
    1965: 1402
    1966: 7841
    1967: 13627

    how to read serial numbers...



    International Harvester 424 Power:

    Drawbar (claimed):32.1 hp [23.9 kW]
    PTO (claimed):36.97 hp [27.6 kW]
    Drawbar (tested):31.90 hp [23.8 kW]
    PTO (tested):36.97 hp [27.6 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Steering:power assist
    Brakes:differential mechanical dry disc
    Cab:Open operator station.


    Battery:

    Volts:12
