Tractors > International Harvester > Hydro 100
      -Brand search:


     International Harvester Tractors 1955-1985
    International Harvester Tractors 1955-1985

    International Harvester Hydro 100

    International Harvester Hydro 100 tractor photo  I&T Manual: IH 544, 656, 666, 686, 684, 784, 884, 1466, 1468, 1486, 1568, 1586, Hydro 70, 84, 86, 100, 186
    I&T Shop Manual
    1973 - 1976   66 Series
    Row-Crop tractor
    Next model:International Harvester Hydro 186
    Larger:International Harvester 1066
    Smaller:International Harvester 966






    Production:

    Manufacturer:International Harvester
    Original price (USD):$21,700 (1976)


    International Harvester Hydro 100 Engine:

       International Harvester 7.1L 6-cyl diesel
    full engine details ...


    Capacity:



    3-Point Hitch:

    Rear Type:II


    Power Take-off (PTO):

    Rear RPMs:540/1000


    Dimensions & Tires:

    Wheelbase:104.8 inches [266 cm]
    Weight:12,130 lbs [5502 kg]
    Front tire:10.00-16
    Rear tire:18.4-34
    full dimensions and tires ...


    Hydro 100 Serial Numbers:

    Location:Hydro drive housing, left side
    1973: 7501
    1974: 7727
    1975: 10915
    1976: 12434

    how to read serial numbers...



    International Harvester Hydro 100 Power:

    Drawbar (claimed):80 hp [59.7 kW]
    PTO (claimed):104.17 hp [77.7 kW]
    Drawbar (tested):78.31 hp [58.4 kW]
    PTO (tested):104.17 hp [77.7 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Steering:hydrostatic power
    Brakes:differential hydraulic dry disc
    Cab:Open operator station. Two-post ROPS and cab available.


    Hydraulics:

    Pump flow:12 gpm [45.4 lpm]


    Battery:
