    International Harvester Hydro 84

    International Harvester Hydro 84 tractor photo  I&T Manual: IH 544, 656, 666, 686, 684, 784, 884, 1466, 1468, 1486, 1568, 1586, Hydro 70, 84, 86, 100, 186
    I&T Shop Manual
    1977 - 1984






    Production:

    Manufacturer:International Harvester
    Factory:Doncaster, England
    Original price (USD):$23,000 (1984)


    International Harvester Hydro 84 Engine:

       International Harvester 4.0L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:20 gal [75.7 L]
    Hydraulic system:16.5 gal [62.5 L]


    3-Point Hitch:

    Rear Type:1/2


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540


    Dimensions & Tires:

    Wheelbase:83.75 inches [212 cm] (low-profile)
     84.8 inches [215 cm] (row-crop)
    Weight:5,970 lbs [2707 kg]
    Front tire:7.50-16
    Rear tire:16.9-30
    full dimensions and tires ...


    Hydro 84 Serial Numbers:

    Location:Front axle on right side of tractor.
    1978: 501
    1979: 787
    1980: 1481
    1981: 5564
    1982: 6014
    1983: 8069

    how to read serial numbers...



    International Harvester Hydro 84 Power:

    Drawbar (claimed):43.6 hp [32.5 kW]
    PTO (claimed):58.7 hp [43.8 kW]
    Drawbar (tested):42.90 hp [32.0 kW]
    PTO (tested):58.73 hp [43.8 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:independent hydraulic wet disc
    Cab:ROPS canopy or cab optional


    Hydraulics:

    Type:open
    Capacity:16.5 gal [62.5 L]
    Valves:1 or 2
    Total flow:13 gpm [49.2 lpm]
     15.4 gpm [58.3 lpm] (optional)


    Battery:

    Number:1
    Volts:12
