    Farmall Super A - engine

    Farmall Super A tractor photo I&T Manual: IH A, B, C, MTA, H, M, MD, Cub, MT, W4, W6, D9
    I&T Shop Manual
    Production years:1947 - 1954
    Previous model:Farmall A
    Next model:Farmall 100
    Tractor type:Farm/Agricultural tractor
    Larger:Farmall Super C
    more Farmall Super A specifications...






    Engine:

    Manufacturer:International Harvester
    Model:C113
    Fuel:gasoline
    Cylinders:4
    Valves:-unknown-
    Bore/Stroke:3.00x4.00 inches [76 x 102 mm]
    Displacement:113.1 ci [1.9 L]
    Cooling:liquid
    Coolant:13 qts [12.3 L]
    Compression:6:1
    Rated RPMs:1400
    Firing order:1-3-4-2
    Starter volts:6
    Sparkplug gap:0.025
    Point gap:0.020
    Intake valve clearance:0.014 hot
    Exhaust valve clearance:0.014 hot


    Engine:

    Manufacturer:International Harvester
    Fuel:kerosene
    Cylinders:4
    Valves:-unknown-
    Bore/Stroke:3.00x4.00 inches [76 x 102 mm]
    Displacement:113.1 ci [1.9 L]
    Cooling:liquid
    Compression:-unknown-
    Rated RPMs:1400
    Firing order:1-3-4-2
    Starter volts:6
