Ford 2610

Ford 2610 tractor photo
1982 - 1983
Previous model:Ford 2600
Series next:Ford 3610
Series back:Ford 2310






Production:

Manufacturer:Ford
Original price (USD):$13,500 (1983)


Ford 2610 Engines:

   Ford 2.9L 3-cyl diesel
   Ford 2.6L 3-cyl gasoline
full engine details ...


Capacity:

Fuel:13 gal [49.2 L]
Rear axle:24.6 qts [23.3 L]


3-Point Hitch:

Rear Type:I
Rear lift (at 24"/610mm):1,975 lbs [895 kg]


Power Take-off (PTO):

Rear PTO:live
Rear RPM:540


Dimensions & Tires:

Wheelbase:75.8 inches [192 cm]
Weight:3475 to 6000 pounds
Front tire:5.50-16
Rear tire:12.4-28
full dimensions and tires ...


Ford 2610 attachments:

 front-end loader
all 2610 attachments ...


2610 Serial Numbers:

1982: C682000
1983: C694500

how to read serial numbers...



Ford 2610 Power:

Engine (gross):42.5 hp [31.7 kW]
Engine:40.5 hp [30.2 kW]
Drawbar (claimed):30 hp [22.4 kW]
PTO (claimed):36 hp [26.8 kW] (diesel)
 34 hp [25.4 kW] (gas)
Drawbar (tested):30.47 hp [22.7 kW]
PTO (tested):36.69 hp [27.4 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
Steering:power assist
Brakes:drum
Cab:Two-post ROPS


Hydraulics:

Type:live
Pressure:2500 psi [172.4 bar]
Pump flow:8.5 gpm [32.2 lpm]
Steering flow:3.6 gpm [13.6 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:32


Battery:

Number:1
Volts:12
Amp-hours:128 (diesel)
 77 (gas)
