Ford FW-20


Ford FW-20 tractor photo
1977 - 1982
FW Series
Four-wheel Drive (4WD) tractor
Steiger built
Series map:
FW-20
FW-30
210.0hp
265.0hp
Production
DistributorFord
ManufacturerSteiger
Four-wheel Drive (4WD) tractor
Built in Fargo, North Dakota, USA
Original price$70,699
Ford FW-20 Engine
Cummins 9.1L 8-cyl diesel
Engine details ...
Ford FW-20 Power
Engine (gross)210 hp
156.6 kW
Drawbar (claimed)155 hp
115.6 kW
PTO (claimed)57 hp (540 RPM)
42.5 kW
 105 hp (1000 RPM)
78.3 kW
Drawbar (tested)150.51 hp
112.2 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesoutboard planetary
Articulated power steering
Hydraulic dry disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Ford FW-20 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel225 gal
851.6 L
Hydraulic system25 gal
94.6 L
Hydraulics
Typeopen center
Capacity25 gal
94.6 L
Pressure2250 psi
155.1 bar
Valves4 or 5
Pump flow33.3 gpm
126.0 lpm
SCV flow20 gpm
75.7 lpm
Tractor hitch
Rear TypeIII
Rear lift (at 24"/610mm)12500 lbs
5670 kg
Power Take-off (PTO)
Rear PTOindependent *Optional. Hydrostatic-driven PTO
Rear PTO Type540/1000
Dimensions & Tires
Wheelbase132.5 inches
336 cm
Weight29615 lbs
13433 kg
Front tire18.4x38
Rear tire18.4x38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps80
Batteries4
Battery CCA475 *Each
Battery volts12
References
FW-20 references literature
4-wheel drive tractors published in 1977, by Ford
