| | Production: |
| Factory: | -unknown- |
| Manufacturer: | Allis Chalmers
|
| Total built: | -unknown- |
| | |
| Allis Chalmers 6-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 51 gal [193.0 L]
13 gal [49.2 L] (optional auxiliary tank)
|
| | |
| Rear Type: | 3/2
|
| Rear lift (at 24"/610mm): | 6,680 lbs [3030 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 540/1000
|
| | |
| Wheelbase: | 106 inches [269 cm]
|
| Weight: | 11,939 lbs [5415 kg]
|
| Front tire: | 11.00x16
|
| Rear tire: | 18.4x38
|
| full dimensions and tires ... | | | |
| Location: | Above PTO shield
|
1978: 1234
1979: 2152
1980: 3399
1981: 4225
|
|
| | Power: |
| Engine: | 173 hp [129.0 kW]
|
| Drawbar (claimed): | 124 hp [92.5 kW]
|
| PTO (claimed): | 146 hp [108.9 kW]
|
| | Mechanical: |
| Chassis: | 4x2 2WD
|
| Steering: | power
|
| Brakes: | -unknown- |
| Cab: | Acousta cab standard, A/C optional
|
|
|
| | Hydraulics: |
| Type: | closed center
|
| Capacity: | -unknown- |
| Total flow: | 45 gpm [170.3 lpm]
|
| Valve flow: | 22 gpm [83.3 lpm]
|
| Steering flow: | -unknown- |
| Pressure: | -unknown- |
| Valves: | 2 or 3
|
| | Electrical: |
| Ground: | -unknown- |
