Allis Chalmers 7000 Engine


Allis Chalmers 7000 tractor photo
1975 - 1979
Row-Crop tractor
200
Series:7000
7010
Engine Detail
Allis Chalmers 2900
turbocharged diesel
6-cylinder
liquid-cooled
The 2900 engine was used on the maroon-chassis Allis 7000, until serial number 8000 in 1978.
Displacement:301 ci
4.9 L
Bore/Stroke:3.875x4.25 inches
98 x 108 mm
Air cleaner:dry
Compression:16.25:1
Rated RPM:2200
Idle RPM:775-2465
Firing order:1-5-3-6-2-4
Starter volts:12
Coolant capacity:22.5 qts
21.3 L
Coolant change:2000 h

Intake valve clearance:0.015 inches
0.381 mm (hot)
Exhaust valve clearance:0.015 inches
0.381 mm (hot)
Engine Oil
7000 diesel engine oil chart
Oil capacity:16 qts
15.1 L
Oil change:100 h

Engine Detail
Allis Chalmers 649T
turbocharged diesel
6-cylinder
liquid-cooled
The black-chassis model 7000 engine was designed the 649T, with several internal changes over the 2900 including new Bosch injectors and oil cooling jets. Rated power did not change.
Displacement:301 ci
4.9 L
Bore/Stroke:3.875x4.25 inches
98 x 108 mm
Compression:16.25:1
Rated RPM:2200
Firing order:1-5-3-6-2-4
Starter volts:12
Coolant capacity:22.5 qts
21.3 L
Page information
Last update:April 28, 2021
Copyright:Copyright 2021 TractorData LLC
Contact:Peter@TractorData.com
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed is accurate. However, differences between sources, incomplete listings, errors, and data entry mistakes do occur. Consult official literature from the manufacturer before attempting any service or repair.
