Allis Chalmers 160


Allis Chalmers 160 tractor photo
1969 - 1973
Utility tractor
Renault built
Series map:
160
40.0hp
Production
DistributorAllis Chalmers
ManufacturerRenault
Utility tractor
Built in France
Total built5,597 (total)
 4,110 (One-Sixty)
 1,487 (160)
Original price$6,215
The Allis-Chalmers 160 was built by Renault. It was based on the model 56, but used a Perkins diesel in place of the MWM. The tractor was badged as the One-Sixty from 1969 through 1971, then as the 160 in 1972.
Allis Chalmers 160 Transmissions
10-speed partial synchronized
6-speed
Transmission details ...
Allis Chalmers 160 Power
Engine40 hp
29.8 kW
Drawbar (tested)36.71 hp
27.4 kW
PTO (tested)40.36 hp
30.1 kW
Performance test details ...
Mechanical
Two-wheel drive
Steeringhydrostatic power
 manual (on basic models)
Differential mechanical dry disc brakes
Open operator station.
Photos
No photos of the Allis Chalmers 160 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel13.5 gal
51.1 L
Hydraulic system7.25 gal
27.4 L
Hydraulics
Capacity7.25 gal
27.4 L
Pressure2300 psi
158.6 bar
Pump flow6.7 gpm
25.4 lpm
Steering flow7.5 gpm
28.4 lpm
Steering press.1100 psi
75.8 bar
Tractor hitch
Rear TypeII
Controllower-link draft sensing
Power Take-off (PTO)
Rear PTOlive
Rear PTO Type540 (1.375)
Engine RPM540@2160
Dimensions & Tires
Wheelbase76 inches
193 cm
Weight4250 to 4680 pounds
Front tire6.00-16
Rear tire13.6-28
Full dimensions and tires ...
160 Serial Numbers
Location:Serial number plate on the front of the metal panel between the engine and fuel tank, right side of the tractor.
Electrical
Groundnegative
Charging systemDelco-Remy
 Paris-Rhone
Battery volts12
Battery AH95
References
160 references literature
The Rugged New 40hp One-Sixty published in 1969, by Allis Chalmers
160 Tractors published in 1972, by Allis Chalmers
