| | Production: |
| Factory: | Japan
|
| Distributor: | John Deere
|
| Manufacturer: | Yanmar
|
| Total built: | -unknown- |
| | |
| Yanmar 4-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 21.1 gal [79.9 L]
|
| | |
| Rear Type: | II
|
| Rear lift: | 2,650 lbs [1202 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 540
|
| | |
| Wheelbase: | 82.8 inches [210 cm]
|
| Weight: | 4,450 lbs [2018 kg]
|
| Front tire: | 6.50-16
|
| Rear tire: | 14.9-28
|
| full dimensions and tires ... | | | |
- Serial numbers unknown -
|
|
| | Power: |
| Engine: | 55 hp [41.0 kW]
|
| Drawbar (claimed): | 38 hp [28.3 kW]
|
| PTO (claimed): | 45 hp [33.6 kW]
|
| Drawbar (tested): | 43.8 hp [32.7 kW]
|
| PTO (tested): | 51.4 hp [38.3 kW]
|
| power test details ... | | | Mechanical: |
| Chassis: | 4x2 2WD
4x4 MFWD 4WD (optional)
|
| Steering: | -unknown- |
| Brakes: | -unknown- |
|
|
| | Hydraulics: |
| Type: | open
|
| Capacity: | 33.3 gal [126.0 L]
|
| Total flow: | -unknown- |
| Valve flow: | 10.7 gpm [40.5 lpm]
|
| Steering flow: | -unknown- |
| Pressure: | -unknown- |
| Valves: | 2
|
| | Electrical: |
| Ground: | -unknown- |
