John Deere 750


John Deere 750 tractor photo
1981 - 1988
50 Compact Series
Compact Utility tractor
Yanmar built
Series map:
650
750
850
17.0hp
20.0hp
25.0hp
Production
DistributorJohn Deere
ManufacturerYanmar
Compact Utility tractor
Built in Japan
Original price$7,070 (1983 )
$10,000 (1989 )
John Deere 750 Power
Engine (gross)20 hp
14.9 kW
PTO (claimed)18.5 hp
13.8 kW
Drawbar (tested)15.30 hp
11.4 kW
PTO (tested)18.54 hp
13.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Steeringmanual
 power OptOptional
Differential mechanical dry, internal expanding shoe brakes
Two-post fixed ROPS.
Capacity
Fuel6.2 gal
23.5 L
Hydraulic system3.75 gal
14.2 L
Hydraulics
Typeopen center
Capacity3.75 gal
14.2 L
Pressure2030 psi
140.0 bar
Valves2 OptOptional
Tractor hitch
Rear TypeI
Controlposition control
Power Take-off (PTO)
Rear PTOtransmission
Clutch200mm over-running dry disc
Rear PTO Type540 (1.375)
Engine RPM540@2300
Front PTOindependent OptOptional
Clutchelectro-magnetic
Dimensions & Tires
Wheelbase61.1 inches
155 cm
Weight1900 to 2000 pounds
Front tire4.00-15
Rear tire9.5-24
Full dimensions and tires ...
John Deere 750 attachments
60" mid-mount mower deck
snowblower
blade
front-end loader
backhoe
Attachment details ...
750 Serial Number Location
John Deere 750 serial number location
Serial number plate on the rear of the John Deere 750, below the PTO shaft.
750 Serial Numbers
19811000
19823448
19835613
19848457
198513001
198618501
198722601
198826450
Final28161

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps15
Battery CCA370
Battery volts12
Battery GroupBCI 24
References
750 references literature
Consumer Products Price List published in 1983, by John Deere
Grounds Care Equipment Purchasing Guide published in 1983, by John Deere
Compact Utility/Utility Tractors Product Information Handbook published in 1983, by John Deere
Compact Utility Tractors published in 1981, by John Deere
Compact Utility Diesel Tractors 14.5 to 40 PTO hp published in 1982, by John Deere
Diesel Tractors 14.5 to 60 PTO hp published in 1984, by John Deere
Mechanical Front-Wheel Drive published in 1984, by John Deere
