    John Deere 1520

    John Deere 1520 tractor photo  I&T Manual: Deere 1020, 1520, 1530, 2020, 2030
    I&T Shop Manual
    Production years:1968 - 1972
    Next model:John Deere 1530
    Tractor type:Farm/Agricultural tractor






    Production:

    Manufacturer:John Deere
    Factory:Dubuque, Iowa, USA
    Mannheim, Baden-Württemberg, Germany
    Total built:-unknown-
    Original price:$5,300 (1973)


    John Deere 1520 Engine:

       John Deere 3-cyl diesel
       John Deere 3-cyl gasoline
    full engine details ...


    Capacity:

    Fuel:19.5 gal [73.8 L]
    Hydraulic system:10 gal [37.9 L]


    3-Point Hitch:

    Rear Type:-unknown-
    Rear lift:2,300 lbs [1043 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540


    Dimensions & Tires:

    Wheelbase:74 inches [187 cm]
    Weight:5770 to 6970 pounds
    Front tire:9.00-10
    Rear tire:14.9-28
    full dimensions and tires ...


    1520 Serial Numbers:

    1968: 76112
    1969: 82405
    1970: 102061
    1971: 117500
    1972: 134700
    1973: 157109


    John Deere 1520 Power:

    Engine:-unknown-
    PTO (claimed):46 hp [34.3 kW]
    Drawbar (tested):38.48 hp [28.7 kW]
    PTO (tested):47.86 hp [35.7 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    Steering:power assist
    Brakes:differential hydraulic wet disc


    Hydraulics:

    Type:closed
    Capacity:10 gal [37.9 L]
    Pressure:-unknown-
    Valves:-unknown-
    Total flow:-unknown-
    Valve flow:10.5 gpm [39.7 lpm]
    Steering flow:-unknown-


    Electrical:

    Ground:-unknown-


    Battery:

    Number:-unknown-
    Cold-cranking amps:-unknown-
    Volts:-unknown-
    Amp-hours:-unknown-
