John Deere 530 Tests
|
|
| Tractor Tests | |
| NTTL 590: LP gas 6-speed 2WD | |
| NTTL 592: tractor fuel 6-speed 2WD | |
| NTTL 597: gasoline 6-speed 2WD |
| Nebraska Tractor Test 590 | |||
| |||
| Nebraska Tractor Test 590 | |
| LP gas 6-speed 2WD September 5 - 11, 1956 Link: Nebraska Tractor Test 590 file | |
| Belt power (max) | 37.24 hp 27.8 kW |
| Belt fuel use (max) | 3.9 gal/hour 14.8 l/hour |
| Drawbar performance | |
| Max power | 33.30 hp 24.8 kW |
| Gear 4 used for power test. | |
| Max pull | 4,659 lbs 2113 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 592 | |||
| |||
| Nebraska Tractor Test 592 | |
| Tractor fuel 6-speed 2WD September 13 - 17, 1956 Link: Nebraska Tractor Test 592 file | |
| Belt power (max) | 25.41 hp 18.9 kW |
| Belt fuel use (max) | 2.5 gal/hour 9.5 l/hour |
| Drawbar performance | |
| Max power | 23.98 hp 17.9 kW |
| Gear 3 used for power test. | |
| Max pull | 4,660 lbs 2113 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 597 | |||
| |||
| Nebraska Tractor Test 597 | |
| Gasoline 6-speed 2WD October 61956, - October 10, 1956 Link: Nebraska Tractor Test 597 file | |
| Belt power (max) | 37.52 hp 28.0 kW |
| Belt fuel use (max) | 3.3 gal/hour 12.5 l/hour |
| Drawbar performance | |
| Max power | 33.27 hp 24.8 kW |
| Gear 4 used for power test. | |
| Max pull | 4,723 lbs 2142 kg |
| Gear 2 used for pull test. | |
