Tractors > John Deere > H

John Deere H - engine

John Deere H tractor photo
1939 - 1947   Two-Cylinder Letter Series
Row-Crop tractor
more John Deere H specifications...






Engine Detail:

 John Deere
 kerosene
 2-cylinder
 liquid-cooled
 99.7 ci [1.6 L]
Bore/Stroke:3.56x5.00 inches [90 x 127 mm]
Air cleaner:oil bath
Compression:4.75 : 1
Rated RPM:1400
Firing order:1-2
Starter:hand-crank
 electric*Electric start became available as an option in 1941, tractor serial number 27000.
Starter volts:6
Oil capacity:4.5 qts [4.3 L]
Coolant capacity:22 qts [20.8 L]
Sparkplug gap:0.030 inches [0.762 mm]
