Tractors > Allis Chalmers > G

Allis Chalmers G - engine

Allis Chalmers G tractor photo
1948 - 1955
Tool Carrier tractor
more Allis Chalmers G specifications...






Engine Detail:

 Continental AN-62
 gasoline
 4-cylinder
 liquid-cooled vertical L-head
 62 ci [1.0 L]
Bore/Stroke:2.375x3.50 inches [60 x 89 mm]
Air cleaner:oil bath
Compression:5.75:1
Rated RPM:1800
Firing order:1-3-4-2
Starter volts:6
Coolant capacity:6.5 qts [6.2 L]
Sparkplug gap:0.025 inches [0.635 mm]
Point gap:0.020 inches [0.508 mm]
Intake valve clearance:0.010 inches [0.254 mm] (hot)
Exhaust valve clearance:0.010 inches [0.254 mm] (hot)
