Ford 450
|
|
| Production | |
| Manufacturer | Ford |
| Backhoe loader tractor | |
| Ford 450 Engine | |
| Ford 3.1L 3-cyl diesel | |
 Engine details ... |
| Ford 450 Transmission | |
| 4-speed torque converter | |
 Transmission details ... |
| Ford 450 Power | |
| Engine (gross) | 52 hp 38.8 kW |
| Engine (net) | 50 hp 37.3 kW |
| PTO (claimed) | 44 hp 32.8 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Mechanical wet disc brakes | |
| Four-post ROPS. | |
| Photos | |
 | |
 Ford 450 photos... | |
| Capacity | |
| Fuel | 16 gal 60.6 L |
| Hydraulic system | 8.7 gal (loader) 32.9 L |
| 22 gal (backhoe) 83.3 L | |
| Steering | 1.25 qts 1.2 L |
| Hydraulics | |
| Type | open center |
| Capacity | 8.7 gal (loader) 32.9 L |
| 22 gal (backhoe) 83.3 L | |
| Pump flow | 21.9 gpm 82.9 lpm |
| Steering flow | 5.9 gpm 22.3 lpm |
| Steering cap. | 1.25 qts 1.2 L |
| Dimensions & Tires | |
| Weight | 11553 lbs 5240 kg |
| Front tire | 11.00L-16 |
| Rear tire | 16.9-24 |
 Full dimensions and tires ... | |
| References | |
 | |
| 450 published in 1987, by Ford |
