Tractors > New Holland > 675E backhoe-loader

New Holland 675E



No photo available
1996 - 1999
Backhoe loader tractor
675D ↑
Series:655E ← 675E
Production
ManufacturerNew Holland
TypeBackhoe loader tractor
New Holland 675E Engine
New Holland 5.0L 4-cyl diesel
Engine details ...
New Holland 675E Transmissions
4-speed power shuttle
4-speed power shift
Transmission details ...
New Holland 675E Power
Engine (gross)100 hp
74.6 kW
Engine (net)98 hp
73.1 kW
Mechanical
Chassis4x2 2WD
 4x4 MFWD 4WD
Final drivesplanetary
Differential lockmechanical
 hydraulic OptOptional
Steeringpower
Brakeshydraulic wet disc
CabFour-post ROPS/FOPS. Cab optional with air-conditioning.
Photos
No photos of the New Holland 675E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel28 gal
106.0 L
Hydraulic system36.2 gal
137.0 L
Hydraulics
Typeopen center
Capacity36.2 gal
137.0 L
Pressure2850 psi
196.5 bar
Pump flow38 gpm
143.8 lpm
Dimensions & Tires
2WD Wheelbase86.3 inches
219 cm
4WD Wheelbase85.6 inches
217 cm
Weight14341 to 16314 pounds
Front tire11L-16
Rear tire19.5Lx24
Full dimensions and tires ...
Backhoe & Loader
Dig depth186 inches
472 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps70
Batteries1
 2 OptOptional
Battery CCA960
Battery volts12
