Tractors > Ford > 555D backhoe-loader

Ford 555D



Ford 555D tractor photo
1993 - 1995
D Series
Backhoe loader tractor
Series map:
455D
555D
575D
66.0hp
72.0hp
82.0hp
Production
ManufacturerFord
Backhoe loader tractor
Ford 555D Engine
Ford 4.2L 4-cyl diesel
Engine details ...
Ford 555D Transmission
4-speed power shuttle
Transmission details ...
Ford 555D Power
Engine (gross)72 hp
53.7 kW
Engine (net)65 hp
48.5 kW
Mechanical
Two- or four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Four-post ROPS/FOPS. Cab optional with air-conditioning.
Photos
No photos of the Ford 555D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel24 gal
90.8 L
Hydraulic system21 gal
79.5 L
Steering2.5 qts
2.4 L
Hydraulics
Typeopen center
Capacity21 gal
79.5 L
Pressure2450 psi
168.9 bar
Pump flow31 gpm
117.3 lpm
Steering flow5.1 gpm
19.3 lpm
Steering cap.2.5 qts
2.4 L
Steering press.1950 psi
134.5 bar
Dimensions & Tires
Wheelbase87 inches
220 cm
Weight13157 to 14224 pounds
Front tire11L-16
Rear tire16.9-28
Full dimensions and tires ...
Backhoe & Loader
Dig depth177 inches
449 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA800
Battery volts12
References
555D references literature
Ford Tractor Loader Backhoe 555D Specifications published in 1989
Tractor Loader Backhoes 445D 555D 575D 655D 675D published in 1994, by Ford
