    Ford 555C

    Ford 555C backhoe photo
    1989 - 1992
    Backhoe loader tractor
    Previous model:Ford 555B
    Next model:Ford 555D






    Production:

    Manufacturer:Ford


    Ford 555C Engine:

       Ford 4.2L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:24 gal [90.8 L]
    Hydraulic system:21 gal [79.5 L]
    Steering:2.4 qts [2.3 L]


    Dimensions & Tires:

    Wheelbase:87 inches [220 cm]
    Weight:14150 lbs [6418 kg]
    Front tire:11L-16
    Rear tire:16.9-28
    full dimensions and tires ...


    Backhoe & Loader:

    Dig depth:177 inches [449 cm]
    Dump angle:56 inches [142 cm]
    full backhoe/loader specifications ...


    555C Serial Numbers:


    - Serial numbers unknown -



    Ford 555C Power:

    Engine (gross):71 hp [52.9 kW]
    Engine (net):65 hp [48.5 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD
    Differential lock:mechanical rear
    Steering:power
    Brakes:wet disc
    Cab:Four-post ROPS/FOPS. Cab available with heater.


    Hydraulics:

    Type:open center
    Capacity:21 gal [79.5 L]
    Pressure:2450 psi [168.9 bar]
    Pump flow:31 gpm [117.3 lpm]
    Steering flow:7.9 gpm [29.9 lpm]
    Steering cap.:2.4 qts [2.3 L]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:55


    Battery:

    Cold-cranking amps:750
    Volts:12
    Amp-hours:128
