Ford 555B
|
|
| Production | |
| Manufacturer | Ford |
| Backhoe loader tractor | |
| Ford 555B Engine | |
| Ford 3.3L 3-cyl diesel | |
 Engine details ... |
| Ford 555B Transmission | |
| 4-speed torque converter | |
 Transmission details ... |
| Ford 555B Power | |
| Engine (gross) | 63 hp 47.0 kW |
| Engine (net) | 62 hp 46.2 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Four-post ROPS canopy. Cab optional with air-conditioner. | |
| Photos | |
 | |
 Ford 555B photos... | |
| Capacity | |
| Fuel | 24 gal 90.8 L |
| Hydraulic system | 13 gal (loader) 49.2 L |
| 21 gal (backhoe) 79.5 L | |
| Steering | 2 qts 1.9 L |
| Hydraulics | |
| Type | open center |
| Capacity | 13 gal (loader) 49.2 L |
| 21 gal (backhoe) 79.5 L | |
| Pressure | 2450 psi 168.9 bar |
| Pump flow | 28.5 gpm 107.9 lpm |
| Steering flow | 5.9 gpm 22.3 lpm |
| Steering cap. | 2 qts 1.9 L |
| Dimensions & Tires | |
| Wheelbase | 80 inches 203 cm |
| Weight | 13440 lbs 6096 kg |
| Front tire | 11L-16 |
| Rear tire | 16.9x28 |
 Full dimensions and tires ... | |
| Backhoe & Loader | |
| Dig depth | 173 inches 439 cm |
| Dump angle | 55 inches 139 cm |
 Loader/Backhoe details ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 51 |
| 72 *72-amp alternator available with cab. | |
| Battery CCA | 750 |
| Battery volts | 12 |
| Battery AH | 128 |
| References | |
 | |
| 1986 Industrial Buyer's Guide published by Ford |
