John Deere 710D


John Deere 710D backhoe photo
1993 - 2003
Backhoe loader tractor
710C
Series:710D
710G
Production
ManufacturerJohn Deere
TypeBackhoe loader tractor
John Deere 710D Engine
John Deere 5.9L 6-cyl diesel
Engine details ...
John Deere 710D Power
Engine (gross)120 hp
89.5 kW
Engine115 hp
85.8 kW
Mechanical
Chassis4x2 2WD
 4x4 MFWD 4WD
Final drivesinboard planetary
Steeringpower
Brakesdifferential hydraulic wet disc
CabFour-post ROPS/FOPS. Cab available cab with optional air-conditioning.
Photos
No photos of the John Deere 710D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel44 gal
166.5 L
Hydraulic system40 gal
151.4 L
Rear axle18 qts
17.0 L
Hydraulics
Typeclosed center
Capacity40 gal
151.4 L
Pressure2550 psi
175.8 bar
Total flow53 gpm
200.6 lpm
Dimensions & Tires
2WD Wheelbase94.5 inches
240 cm
4WD Wheelbase96.5 inches
245 cm
Weight23000 to 25400 pounds
Front tire14.5/75-16.1
Rear tire21L-24
Full dimensions and tires ...
Backhoe & Loader
Dig depth218 inches
553 cm
Dump angle40 inches
101 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps95
Battery volts12
References
710D reference literature
Utility/Construction Purchasing Guide published in 1995, by John Deere
