General tractor information: |
| Manufacturer: | Farmall
|
| Model: | 1206
|
| Type: | Farm/Agricultural tractor
|
| Total built: | 1,289 (IH/wheatland)
8,400 (Farmall/row-crop)
|
| Factory: | -unknown- |
| Original price: | $9,450 (1967)
|
| |
Tractor power: |
| Drawbar (rated): | 99 hp [73.8 kW]
|
| Drawbar (max): | 95.00 hp [70.8 kW]
|
| PTO (rated): | 112.64 hp [84.0 kW]
|
 |
 |
| |
Variants: |
| IH 1206: | standard front
|
| Farmall 1206: | row-crop
|
| Wheatland: | larger platform, heavy drawbar
|
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | DT361
|
| Fuel: | diesel
|
| Aspiration: | turbocharged
|
| Cylinders: | 6
|
| Bore/Stroke: | 4.125x4.25 inches [105 x 108 mm]
|
| Displacement: | 361 ci [5.9 L]
|
| Compression: | 17.0:1
|
| Rated RPMs: | 2400
|
| Cooling: | liquid
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| |
Transmission: |
| Type: | -unknown- |
| Forward: | 8
|
| Reverse: | 4
|
| |
Transmission: |
| Type: | Torque Amplifier
|
| Forward: | 16
|
| Reverse: | 8
|
| Comments: | The Torque Amplifier (TA) provides a clutchless power shift between Direct Drive (DD) and the lower TA gearing.
|
| Speeds: | | Gear | rpm | | 1-TA | 1.5mph [2.4kph] | | 1-DD | 1.75mph [2.8kph] | | 2-TA | 2mph [3.2kph] | | 2-DD | 2.5mph [4.0kph] | | 3-TA | 3.25mph [5.2kph] | | 3-DD | 4.1mph [6.6kph] | | 4-TA | 4.4mph [7.1kph] | | 4-DD | 5mph [8.0kph] | | 5-TA | 5.5mph [8.8kph] | | 5-DD | 6.25mph [10.1kph] | | 6-TA | 6.5mph [10.5kph] | | 6-DD | 8.5mph [13.7kph] | | 7-TA | 11.5mph [18.5kph] | | 7-DD | 14.5mph [23.3kph] | | 8-TA | 15.25mph [24.5kph] | | 8-DD | 19.5mph [31.4kph] | | 1R-TA | 2.5mph [4.0kph] | | 1R-DD | 3mph [4.8kph] | | 2R-TA | 3.25mph [5.2kph] | | 2R-DD | 4.25mph [6.8kph] | | 3R-TA | 5.5mph [8.8kph] | | 3R-DD | 7.25mph [11.7kph] | | 4R-TA | 7.5mph [12.1kph] | | 4R-DD | 9.5mph [15.3kph] |
|
|
|
|
| |
Mechanical: |
| Chassis: | 4x2 2WD
4x4 FWA 4WD (optional)
|
| Steering: | hydrostatic power
|
| Brakes: | differential hydraulic dry disc
|
| Cab: | Open operator station. Optional one-door cab. Optional heat and air-conditioning.
|
| |
Capacity: |
| Fuel: | 35 gal [132 L]
|
| |
3-Point Hitch: |
| Rear Hitch Category: | III
|
| Rear lift: | -unknown- |
| |
|
| Rear PTO: | independent
|
| Rear speed (RPM): | 1000
|
| |
Hydraulics: |
| Type: | -unknown- |
| Capacity: | -unknown- |
| Total flow: | -unknown- |
| Valve flow: | 12 gpm [45.4 lpm]
|
| Pressure: | -unknown- |
| Valves: | 0 to 2
|
| |
Tires: |
| Ag front: | 7.50-16
|
| Ag rear: | 18.4-38
|
| |
Dimensions: |
| Weight (operating): | 10,115 lbs [4588 kg]
|
| Weight (ballasted): | 13,580 lbs [6159 kg]
|
| Wheelbase: | -unknown- |
| Length: | -unknown- |
| Width: | -unknown- |
| Height: | -unknown- |
| Ground clearance: | -unknown- |
| |
Electrical: |
| |
Battery: |
| Number: | 2
|
| Volts: | 6
|
| |
Nebraska Tractor Test 910: |
| Test Date: | September 8 - 23, 1965
|
| Type: | Torque Amplifier 2WD
|
| Engine: | diesel
|
| PTO (rated eng speed): | 112.64 hp [84.0 kW]
|
| PTO fuel use (rated): | 15.95 hh/g [3.1 kWh/l]
|
| Drawbar (max): | 95.00 hp [70.8 kW]
|
| Test report: | PDF file
|
| |
|
| Location: On clutch housing, left side |
| |
| 1965: 7501 (Farmall) |
| 1966: 8626 (Farmall) |
| 1967: 12731 (Farmall) |
| 1965: 7501 (IH) |
| 1966: 7772 (IH) |
| 1967: 8492 (IH) |
| |
