General tractor information: |
| Manufacturer: | Farmall
|
| Model: | 826
|
| Type: | Farm/Agricultural tractor
|
| Total built: | -unknown- |
| Factory: | -unknown- |
| Original price: | $9,600 (1971)
|
| |
Tractor power: |
| Drawbar (rated): | 79 hp [58.9 kW] gear
61 hp [45.5 kW] hydro
|
| Drawbar (max): | 78.9 hp [58.8 kW]
|
| PTO (max): | 92.2 hp [68.8 kW]
|
| PTO (rated): | 92 hp [68.6 kW]
|
 |
 |
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | D358
|
| Fuel: | diesel
|
| Cylinders: | 6
|
| Bore/Stroke: | 3.875x5.0625 inches [98 x 129 mm]
|
| Displacement: | 358 ci [5.9 L]
|
| Compression: | -unknown- |
| Rated RPMs: | 2400
|
| Cooling: | liquid
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | D360
|
| Fuel: | diesel
|
| Cylinders: | 6
|
| Bore/Stroke: | 3.875x5.0625 inches [98 x 129 mm]
|
| Displacement: | 360 ci [5.9 L]
|
| Compression: | -unknown- |
| Rated RPMs: | -unknown- |
| Cooling: | liquid
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | C301
|
| Fuel: | gasoline
|
| Cylinders: | 6
|
| Bore/Stroke: | 3.8125x4.39 inches [97 x 112 mm]
|
| Displacement: | 301 ci [4.9 L]
|
| Compression: | -unknown- |
| Rated RPMs: | -unknown- |
| Cooling: | liquid
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| |
Transmission: |
| Type: | sliding gear
|
| Forward: | 8
|
| Reverse: | 4
|
| |
Transmission: |
| Type: | hydrostatic
|
| Forward: | infinite
|
| Reverse: | infinite
|
|
|
|
| |
Mechanical: |
| Chassis: | 4x2 2WD
4x4 MFWD 4WD optional
|
| Steering: | -unknown- |
| Brakes: | -unknown- |
| Cab: | optional
|
| |
Capacity: |
| Fuel: | 37 gal [140 L]
|
| |
3-Point Hitch: |
| Rear Hitch Category: | II
|
| Rear lift: | -unknown- |
| |
|
| Rear PTO: | independent
|
| Rear speed (RPM): | 540
|
| |
Hydraulics: |
| Type: | open
|
| Capacity: | -unknown- |
| Total flow: | -unknown- |
| Valve flow: | -unknown- |
| Pressure: | -unknown- |
| Valves: | -unknown- |
| |
Tires: |
| Ag front: | 9.5L-15
|
| Ag rear: | 18.4-34
|
| |
Dimensions: |
| Weight: | 8581 lbs [3892 kg]
|
| Wheelbase: | 105 inches [266 cm]
|
| Length: | -unknown- |
| Width: | -unknown- |
| Height: | -unknown- |
| Ground clearance: | -unknown- |
| |
Electrical: |
| |
Nebraska Tractor Test 1045: |
| Test Date: | June 1970
|
| Type: | gear
|
| Engine: | diesel
|
| PTO (max): | 92.2 hp [68.8 kW]
|
| Drawbar (max): | 78.9 hp [58.8 kW]
|
| |
Nebraska Tractor Test 1046: |
| Test Date: | June 1970
|
| Type: | hydro
|
| Engine: | diesel
|
| PTO (max): | 84.7 hp [63.2 kW]
|
| Drawbar (max): | 61.4 hp [45.8 kW]
|
| |
|
| Location: Clutch housing, left side |
| |
| 1969: 7501 (Farmall) |
| 1970: 8153 (Farmall) |
| 1971: 16352 (Farmall) |
| 1969: 7501 (IH) |
| 1970: 7518 (IH) |
| 1971: 7719 (IH) |
| |
