General tractor information: |
| Manufacturer: | Farmall
|
| Brand: | Farmall
|
| Model: | 656
|
| Type: | Farm/Agricultural tractor
|
| Total built: | -unknown- |
| Factory: | -unknown- |
| Original price: | -unknown- |
| |
Tractor power: |
| Drawbar (rated): | 54 hp [40.3 kW]
|
| Drawbar (max): | 53.23 hp [39.7 kW]
|
| PTO (rated): | 66.06 hp [49.3 kW]
|
| Plows: | 4-5
|
 |
 |
| |
Variants: |
| IH 656: | utility tractor
|
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | D-282
|
| Fuel: | diesel
|
| Cylinders: | 6
|
| Bore/Stroke: | 3.6875x4.39 inches [94 x 112 mm]
|
| Displacement: | 282 ci [4.6 L]
|
| Compression: | 17.6:1
|
| Rated RPMs: | 1800 (early) 2300 (later)
|
| Cooling: | liquid
|
| Coolant: | 21.5 qts [20.3 L]
|
| Torque: | -unknown- |
| Firing order: | 1-5-3-6-2-4
|
| Oil capacity: | 9 qts [8.5 L]
|
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | C-263
|
| Fuel: | gasoline
|
| Cylinders: | 6
|
| Bore/Stroke: | 3.5625x4.39 inches [90 x 112 mm]
|
| Displacement: | 263 ci [4.3 L]
|
| Compression: | 7.6:1
|
| Rated RPMs: | 1800
|
| Cooling: | liquid
|
| Coolant: | 20.5 qts [19.4 L]
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| Oil capacity: | 9 qts [8.5 L]
|
| |
Engine: |
| Manufacturer: | International Harvester
|
| Model: | C-263
|
| Fuel: | LP gas
|
| Cylinders: | 6
|
| Bore/Stroke: | 3.5625x4.39 inches [90 x 112 mm]
|
| Displacement: | 263 ci [4.3 L]
|
| Compression: | 8.8:1
|
| Rated RPMs: | 1800 (early) 2300 (late)
|
| Cooling: | liquid
|
| Coolant: | 21 qts [19.9 L]
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| Oil capacity: | 9 qts [8.5 L]
|
| |
Transmission: |
| Type: | gear
|
| Forward: | 5
|
| Reverse: | 1
|
| Capacity: | 68 qts [64.4 L]
|
| Speeds: | With 15.5-38 rear tires.
| Gear | 1800 rpm | | 1 | 2.5mph [4.0kph] | | 2 | 4mph [6.4kph] | | 3 | 5mph [8.0kph] | | 4 | 7mph [11.3kph] | | 5 | 15.75mph [25.3kph] | | R | 2.75mph [4.4kph] |
|
| |
Transmission: |
| Type: | Torque Amplifier
|
| Forward: | 10
|
| Reverse: | 2
|
| Capacity: | 68 qts [64.4 L]
|
| Speeds: | With 15.5-38 rear tires.
| Gear | 1800 rpm | | 1-TA | 1.75mph [2.8kph] | | 1-DD | 2.5mph [4.0kph] | | 2-TA | 2.75mph [4.4kph] | | 2-DD | 4mph [6.4kph] | | 3-TA | 3.25mph [5.2kph] | | 3-DD | 5mph [8.0kph] | | 4-TA | 4.75mph [7.6kph] | | 4-DD | 7mph [11.3kph] | | 5-TA | 10.75mph [17.3kph] | | 5-DD | 15.75mph [25.3kph] | | R-TA | 2mph [3.2kph] | | R-DD | 2.75mph [4.4kph] |
|
| |
Transmission: |
| Type: | hydrostatic
|
| Forward: | infinite (2-range)
|
| Reverse: | infinite (2-range)
|
| Speeds: | | Gear | 1800 rpm | | Lo-Max | 7.75mph [12.5kph] | | Hi-Max | 21mph [33.8kph] |
|
 |
|
|
| |
Mechanical: |
| Chassis: | 4x2 2WD
|
| Steering: | hydrostatic power
|
| Brakes: | independent mechanical disc
|
| |
Capacity: |
| Fuel: | 33 gal [124 L] (gas/diesel) 39 gal [147 L] (LP gas)
|
| |
3-Point Hitch: |
| Rear Hitch Category: | 2/1
|
| Rear lift: | -unknown- |
| |
|
| Rear PTO: | independent
|
| Rear speed (RPM): | 540/1000
|
| |
Tires: |
| Ag front: | 6.00-16
|
| Ag rear: | 15.5-38
|
| |
Dimensions: |
| Weight: | 6,250 lbs [2835 kg] (gasoline shipping) 6,430 lbs [2916 kg] (LP gas shipping) 6,520 lbs [2957 kg] (diesel shipping) 7,230 lbs [3279 kg] (diesel operating) 9,235 lbs [4188 kg] (ballasted)
|
| Wheelbase: | 96 inches [243 cm]
|
| Length: | 152 inches [386 cm]
|
| Width: | 87 inches [220 cm]
|
| Height: | 77 inches [195 cm] (steering wheel)
|
| Ground clearance: | 13 inches [33 cm] (drawbar) 21 inches [53 cm] (front axle)
|
| 2WD turn circle: | 9.7 feet [3.0 m] 9.2 feet [2.8 m] (with brakes)
|
| |
Electrical: |
| Starter volts: | 12
|
| Amps: | 25
|
| |
Battery: |
| Number: | 1 (gas/LP) 2 (diesel)
|
| Ampere-hours (ah): | 50 (gas) 60 (LP) 130 (diesel)
|
| Volts: | 12 (gas/LP) 6 (diesel)
|
| |
Nebraska Tractor Test 909: |
| Test Date: | September 9 - 17, 1965
|
| Type: | Torque Amplifier
|
| Engine: | gasoline
|
| PTO (rated eng speed): | 63.85 hp [47.6 kW]
|
| PTO fuel use (rated): | 12.26 hh/g [2.4 kWh/l]
|
| Drawbar (max): | 53.23 hp [39.7 kW]
|
| |
Nebraska Tractor Test 912: |
| Test Date: | September 16 - 23, 1965
|
| Type: | Torque Amplifier
|
| Engine: | diesel
|
| PTO (rated eng speed): | 61.52 hp [45.9 kW]
|
| PTO fuel use (rated): | 14.38 hh/g [2.8 kWh/l]
|
| Drawbar (max): | 52.98 hp [39.5 kW]
|
| |
Nebraska Tractor Test 967: |
| Test Date: | October 31 - November 29, 1967
|
| Type: | hydrostatic
|
| Engine: | diesel
|
| PTO (rated eng speed): | 66.06 hp [49.3 kW]
|
| PTO fuel use (rated): | 12.21 hh/g [2.4 kWh/l]
|
| Drawbar (max): | 50.50 hp [37.7 kW]
|
| |
Nebraska Tractor Test 968: |
| Test Date: | October 31 - November 29, 1967
|
| Type: | hydrostatic
|
| Engine: | gasoline
|
| PTO (rated eng speed): | 65.8 hp [49.1 kW]
|
| PTO fuel use (rated): | 10.41 hh/g [2.1 kWh/l]
|
| Drawbar (max): | 50.09 hp [37.4 kW]
|
| |
|
| Location: Clutch housing, right side |
|   |
| 1965: 8501 |
| 1966: 15505 |
| 1967: 24372 |
| 1968: 32007 |
| 1969: 38861 |
| 1970: 42518 |
| 1971: 45497 |
| 1972: 47951 |
| |
