General tractor information: |
| Manufacturer: | International Harvester
|
| Model: | TD-340
|
| Type: | Farm/Agricultural tractor
|
| Total built: | -unknown- |
| Factory: | Melrose Park, Illinois, USA
|
| Original price: | -unknown- |
| |
Tractor power: |
| Drawbar (rated): | 33 hp [24.6 kW]
|
| Drawbar (max): | 31.6 hp [23.6 kW]
|
| Belt: | 40 hp [29.8 kW]
|
 |
 |
| |
Variants: |
| T-340: | gasoline
|
| |
Engine: |
| Manufacturer: | International Harvester
|
| Fuel: | diesel
|
| Aspiration: | natural
|
| Type: | vertical L-head
|
| Cylinders: | 4
|
| Bore/Stroke: | 3.6875x3.875 inches [94 x 98 mm]
|
| Displacement: | 166 ci [2.7 L]
|
| Compression: | 19.7:1
|
| Rated RPMs: | 2000
|
| Cooling: | liquid
|
| Torque: | -unknown- |
| Firing order: | -unknown- |
| |
Transmission: |
| Type: | -unknown- |
| Forward: | 5
|
| Reverse: | 1
|
|
|
|
| |
Mechanical: |
| Chassis: | crawler
|
| Steering: | -unknown- |
| Brakes: | -unknown- |
| |
Capacity: |
| Fuel: | 15 gal [56 L]
|
| |
|
| |
Tires: |
| Ag front: | tracks
|
| Ag rear: | tracks
|
| |
Dimensions: |
| Weight: | 5,800 lbs [2630 kg]
|
| Wheelbase: | -unknown- |
| Length: | 125 inches [317 cm]
|
| Width: | 58 inches [147 cm]
|
| Height: | 60.3 inches [153 cm]
|
| Ground clearance: | -unknown- |
| |
Electrical: |
| Starter volts: | 12
|
| |
Battery: |
| Number: | 2
|
| Volts: | 6
|
| |
Nebraska Tractor Test 776: |
| Test Date: | October 1960
|
| Engine: | diesel
|
| Belt (max): | 39.8 hp [29.7 kW]
|
| Drawbar (max): | 31.6 hp [23.6 kW]
|
| |
|
| Location: instrument panel |
| |
| 1959: 501 |
| 1960: 1979 |
| 1961: 4344 |
| 1962: 5449 |
| 1963: 6397 |
| 1964: 7338 |
| 1965: 8525 |
| |
