Bush Hog D4-10


Bush Hog D4-10 lawn tractor photo
1966 - 1971
Garden tractor
Series map:
D4-7
D4-10
D4-12
7.3hp
10.0hp
12.0hp
Production
ManufacturerBush Hog
Garden tractor
Built in Galesburg, Kansas, USA
Bush Hog D4-10 Engine
10HP Wisconsin 331cc 1-cyl gasoline
Fuel tank1 gal
3.8 L
Engine details ...
Mechanical
Two-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Bush Hog D4-10 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchmanual
Dimensions & Tires
Wheelbase49 inches
124 cm
Weight640 lbs
290 kg
Front tire16x6.50-8
Rear tire23x8.50-12
Full dimensions and tires ...
Bush Hog D4-10 attachments
32" mid-mount mower deck
42" mid-mount mower deck
snowblower
blade
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
D4-10 references literature
The garden tractor that's all muscle published in 1966, by Bush Hog
