Lawn Tractors > Ariens > Fairway 5

Ariens Fairway 5

Ariens Fairway 5 lawn tractor photo
1967 - 1976   Fairway Series
Model years
Riding lawn mower
Series next:Ariens Fairway 6






Production:

Manufacturer:Ariens
Factory:Brillion, Wisconsin, USA


Variants:

12995:recoil start
12984:electric start
12981:Briggs engine


Ariens Fairway 5 Engine:

   5HP Lauson 1-cyl gasoline
full engine details ...


Capacity:

Fuel:0.5 gal [1.9 L]


Power Take-off (PTO):

Mid PTO:independent
Clutch:mechanical idler


Dimensions & Tires:

Wheelbase:37.5 inches [95 cm]
Weight:221 lbs [100 kg]
Front tire:4.10x3.50-4
Rear tire:12.5x4.50-6
full dimensions and tires ...


Ariens Fairway 5 attachments:

 26" mid-mount mower deck
all Fairway 5 attachments ...


Fairway 5 Serial Numbers:


- Serial numbers unknown -



Mechanical:

Transmission:4-speed friction disk
Chassis:4x2 2WD
Steering:manual
Brakes:mechanical band
Cab:Open operator station.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
