Jacobsen 53500
|
|
| Production | |
| Manufacturer | Jacobsen |
| Garden tractor | |
| Variants | |
| LGT-195 | similar Ford model |
| Jacobsen 53500 Engine | |
| 19.9HP Kohler 879cc 2-cyl gasoline | |
| Fuel tank | 7 gal 26.5 L |
 Engine details ... | |
| Jacobsen 53500 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Mechanical | |
| Two-wheel drive | |
| Steering | power assist |
| Mechanical drum brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Jacobsen 53500 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | 0 OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear RPM | 540 OptOptional |
| 2000 OptOptional | |
| Front PTO | independent |
| Clutch | electric |
| Dimensions & Tires | |
| Wheelbase | 56 inches 142 cm |
| Weight | 1125 lbs 510 kg |
| Front tire | 18x8.50-8 |
| Rear tire | 26x12.00-12 |
 Full dimensions and tires ... | |
| Jacobsen 53500 attachments | |
| 60" mid-mount mower deck | |
| snowblower | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | solid state regulator rectifier |
| Charging amps | 15 |
| Battery volts | 12 |
| Battery AH | 42 |
| References | |
 | |
| Tractors engineered to do more. published in 1978, by Jacobsen |
