Simplicity 7117 Engine


Simplicity 7117 lawn tractor photo
1979 - 1989
7100 Series
Garden tractor
Series map:
7116
7117
7119
16.0hp
17.0hp
19.0hp
Engine Detail
Kohler KT-17
gasoline
2-cylinder
air-cooled horizontal-shaft horizontally-opposed
Displacement691 cc
42.18 ci
Bore/Stroke3.125x2.75 inches
79 x 70 mm
Power (gross)17 hp
12.7 kW
Starterelectric
Starter volts12
Simplicity 7117 Engine
Simplicity 7117 engine image
