John Deere X324


John Deere X324 lawn tractor photo
2006 - 2015
Model year
Select X300 Series
Lawn tractor
Series map:
X320
X324
X360
22.0hp
22.0hp
22.0hp
Production
ManufacturerJohn Deere
Lawn tractor
Built in Horicon, Wisconsin, USA
Variants
X320manual two-wheel steer
X324manual four-wheel steer
X360power two-wheel steer
John Deere X324 Engine
22HP Kawasaki 726cc 2-cyl gasoline
Fuel tank3.5 gal
13.2 L
Engine details ...
Mechanical
Two-wheel drive
Manual four-wheel steering
Open operator station. Optional sunshade and vinyl weather enclosure. Adjustable seat with seven inches of travel. Cupholder and tool tray standard.
Photos
No photos of the John Deere X324 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase49.4 inches
125 cm
Weight581 lbs
263 kg
Front tire15x6-6
Rear tire20x10-10
Full dimensions and tires ...
John Deere X324 attachments
48" mid-mount mower deck
snowblower
blade
Attachment details ...
X324 Serial Numbers
2006010001
2007040001
2008085001
2009120001
2010150001
2011180001
2012220001
2013250001
2014280001
2015310001

FAQ: How to read a serial number table.
X324 Serial Location
John Deere X324 serial number location
Serial number decal on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging amps15
Battery CCA195
Battery volts12
References
X324 references literature
Riding Lawn Tractors published in 2015, by John Deere
Select Series Tractors published in 2012, by John Deere
Riding Lawn Equipment Attachments & Accessories published in 2011, by John Deere
X324 manuals literature
Operator's Manual X300 Tractors (OMM163031) published in 2010
Operator's Manual X300 Tractors (OMM164717) published in 2012
Operator's Manual X300 Tractors (OMM167789) published in 2012
Operator's Manual X300 Tractors (OMM173266) published in 2014
