Lawn Tractors > J.I. Case > 444

J.I. Case 444 - transmission

J.I. Case 444 lawn tractor photo
1969 - 1988   400 Series
Model years
Garden tractor
Series next:J.I. Case 446
Series back:J.I. Case 442
more J.I. Case 444 specifications...






Transmission:

Transmission:HY-Driv
Type:hydraulic drive
Gears:infinite (2-range) forward and reverse
Oil capacity:6.5 qts [6.2 L]
Oil type:
32oF [0oC] : SAE20W40
32oF [0oC] : SAE5W20

The HY-Drive uses a fixed-displacement hydraulic pump to power a two-speed transaxle.
Speeds:
444 HY-Driv hydraulic drive speeds
