John Deere 325 Engine


John Deere 325 lawn tractor photo
1995 - 2001
300 Series
Garden tractor
Series map:
325
335
17.0hp
20.0hp
Engines overview
17HP Kawasaki 534cc 1-cyl gasoline
18HP Kawasaki 493cc 2-cyl gasoline
Engine Detail
Kawasaki FC540V
gasoline
1-cylinder
air-cooled vertical-shaft
The single-cylinder FC540V was used on the Deere 325 through the 1998 model year.
Displacement534 cc
32.64 ci
Bore/Stroke3.50x3.38 inches
89 x 86 mm
Power17 hp
12.7 kW
Fuel systemcarburetor
Air cleanerdry with foam precleaner
Compression8.3:1
Idle RPM1400-3350
Starterelectric
Starter volts12
Oil capacity1.9 qts
1.8 L
John Deere 325 Engine
John Deere 325 engine image
Image courtesy of Chris Jenuwine
Engine Detail
Kawasaki FH531V
gasoline
2-cylinder
air-cooled vertical-shaft V-Twin
The V-Twin Kawasaki FH531V was first used in 1999 (serial number 070001) on the John Deere 325.
Displacement493 cc
30.1 ci
Bore/Stroke2.68x2.68 inches
68 x 68 mm
Power (gross)18 hp
13.4 kW
Air cleanerpaper with foam precleaner
Rated RPM3600
Starterelectric
Starter volts12
Oil capacity1.9 qts
1.8 L
Sparkplug gap0.028 inches
0.711 mm
