| | 1979 - 1985 |
| 900 Series | | Garden tractor |
|
Series map:
912
914
916
12.0hp
14.0hp
16.0hp
| Transmissions overview |
| hydrostatic |
| 4-speed shuttle |
| Transmission |
| Type | belt-driven hydrostatic
|
| Gears | infinite forward and reverse
|
| Oil capacity | 3 qts
2.8 L
|
| Oil type | | Allis-Chalmers Power Fluid 821 |
|
| Oil change | 400 h
|
| Speeds |
|
| Transmission |
| Type | shuttle
|
| Gears | 4 forward and reverse
|
| Speeds |
|
