Caterpillar D9H


Caterpillar D9H industrial tractor photo
1974 - 1981
Industrial Crawler tractor
Series map:
D9H
410.0hp
Production
ManufacturerCaterpillar
Industrial Crawler tractor
Built in Peoria, Illinois, USA
Variants
DD9Htandem D9s
SxS D9Hside-by-side D9Hs
Caterpillar D9H Engine
Caterpillar 24.1L 6-cyl diesel
Fuel tank230 gal
870.6 L
Engine details ...
Caterpillar D9H Power
Engine (net)410 hp
305.7 kW
Mechanical
Drivecrawler
Final drivesplanetary
Cab optional with available air-conditioning.
Photos
No photos of the Caterpillar D9H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tracks
Weight72400 lbs
32840 kg
24-inch tracks
Full dimensions and tracks ...
Electrical
Charging systemalternator
Charging amps19
Batteries2
Battery volts12
Battery AH200
References
D9H references literature
Track-Type Tractors published in 1980, by Caterpillar
perspective on production published by Caterpillar
D7G - D8K - D9H published by Caterpillar
D9H Track-Type Tractor published in 1974, by Caterpillar
