International Harvester Super AI Engine
|
|
| AI ↑ | |
| Series: | Super AI |
| Engines overview | |
| International Harvester 1.9L 4-cyl gasoline | |
| International Harvester 1.9L 4-cyl kerosene |
| Engine Detail | |
| International Harvester C113 | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 113.1 ci 1.9 L |
| Bore/Stroke | 3.00x4.00 inches 76 x 102 mm |
| Compression | 6:1 |
| Rated RPM | 1400 |
| Idle RPM | 500-1540 |
| Firing order | 1-3-4-2 |
| Starter volts | 6 |
| Coolant capacity | 13 qts 12.3 L |
| Sparkplug gap | 0.025 inches 0.635 mm |
| Point gap | 0.020 inches 0.508 mm |
| Intake valve clearance | 0.014 inches (hot) 0.356 mm |
| Exhaust valve clearance | 0.014 inches (hot) 0.356 mm |
| Engine Oil | |
| |
| Oil capacity | 5 qts 4.7 L |
| Oil change | 120 h |
| Engine Detail | |
| International Harvester | |
| kerosene | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 113.1 ci 1.9 L |
| Bore/Stroke | 3.00x4.00 inches 76 x 102 mm |
| Rated RPM | 1400 |
| Firing order | 1-3-4-2 |
| Starter volts | 6 |
