International Harvester 3616 Transmission


International Harvester 3616 industrial tractor photo
1965 - 1971
Industrial tractor
Transmissions overview
5-speed unsynchronized gear
4-speed
5-speed unsynchronized shuttle
hydrostatic
Transmission
Typeunsynchronized gear
Gears5 forward and 1 reverse
Oil capacity80 qts
75.7 L
Oil type
IH B-6
Speeds
With 14.9-28 rear tires.
3616  unsynchronized gear speeds
Transmission
TransmissionHydra-Shuttle
Gears4 forward and reverse
Oil capacity80 qts
75.7 L
Oil type
IH B-6
Speeds
With 14.9-28 rear tires.
3616 Hydra-Shuttle  speeds
Transmission
Typeunsynchronized shuttle
Gears5 forward and reverse
Oil capacity80 qts
75.7 L
Oil type
IH B-6
Speeds
With 14.9-28 rear tires.
3616  unsynchronized shuttle speeds
Transmission
Typehydrostatic
Gearsinfinite forward and reverse (2-range)
Oil capacity80 qts
75.7 L
Oil type
IH B-6
Speeds
With 14.9-28 rear tires.
3616  hydrostatic speeds
