Fendt 207V


Fendt 207V tractor photo
2003 - 2009
Farmer 200 Series
Orchard/Vineyard tractor
Farmer 270V
Series:206V207V208V
Production
Manufacturer:Fendt (a part of AGCO)
Type:Orchard/Vineyard tractor
Variants
207S:utility
207V:ultra-narrow
207F:narrow
Fendt 207V Power
Engine (gross):71.1 hp
53.0 kW
Engine (net):68.4 hp
51.0 kW
Fendt 207V Engine
Deutz 3.2L 3-cyl diesel
Fuel tank:18.5 gal
70.0 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:hydraulic disc
Cab:Cab standard with available heat and air-conditioning. Two-post mid-ROPS available.
Transmissions:20-speed synchromesh
 20-speed shuttle
Transmission details ...
Photos
No photos of the Fendt 207V are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2900 psi
200.0 bar
Rear valves:4*Optional
Mid valves:6*Optional
Pump flow:19.6 gpm
74.2 lpm
 12.4 gpm
46.9 lpm *Optional
Tractor hitch
Rear lift:5983 lbs
2713 kg
Front lift:5355 lbs
2429 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/750/1000
 540/750/ground*Optional
Front PTO:independent*Optional
Front RPM:540
 1000
Dimensions & Tires
207V Wheelbase:78.7 inches
199 cm
207F Wheelbase:79.8 inches
202 cm
Weight:4850 to 5743 pounds
Front tire:6.00-16
207V 2WD Rear tire:280/85R24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:55
Charging volts:14
Battery volts:12
Battery AH:88
