TYM T654
| Production |
| Manufacturer: | TYM
|
| Type: | Utility tractor
|
| TYM T654 Power |
| Engine (gross): | 67 hp
50.0 kW
|
| PTO (claimed): | 61.9 hp
46.2 kW
|
| Mechanical |
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmissions: | 24-speed sync shuttle
|
| | 24-speed power shuttle
|
 Transmission details ... |
| Photos |
| No photos of the TYM T654 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pump flow: | 10.3 gpm
39.0 lpm
|
| Total flow: | 16.1 gpm
60.9 lpm
|
| Steering flow: | 5.8 gpm
22.0 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 4270 lbs
1936 kg
|
| Rear lift (at 24"/610mm): | 3153 lbs
1430 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Electrical |
| Ground: | negative
|
| Charging amps: | 95
|
| Battery volts: | 12
|
