Tractors > Kubota > GL-430

Kubota GL-430

Kubota GL-430 tractor photo
1995 - 1998   GL Series
Compact Utility tractor
Previous model:Kubota GL-43
Series next:Kubota GL-470
Series back:Kubota GL-400






Production:

Manufacturer:Kubota


Kubota GL-430 Engine:

   Kubota 1.5L 3-cyl diesel
full engine details ...


Capacity:

Fuel:13.2 gal [50.0 L]


3-Point Hitch:

Rear Type:JIS1


Power Take-off (PTO):

Rear RPM:540 (1.375)
Engine RPM:578@2700
781@2700
950@2700
1249@2700
-781@2700


Dimensions & Tires:

Wheelbase:72.8 inches [184 cm]
Weight:3527 to 3825 pounds
Front tire:8-18
Rear tire:13.6-26
full dimensions and tires ...


GL-430 Serial Numbers:


how to read serial numbers...



Kubota GL-430 Power:

Engine:43 hp [32.1 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Cab:Two-post ROPS. Cab optional.


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
