Mahindra Max 25XL


No photo available
2018 - 2023
Compact Utility tractor
TYM built
Series map:
Max 25XL
Max 26XLT
24.0hp
25.9hp
Production
DistributorMahindra
ManufacturerTYM
Compact Utility tractor
Original price was $16,730 in 2019
Mahindra Max 25XL Engine
Mitsubishi 1.3L 3-cyl diesel
Fuel tank6.1 gal
23.1 L
Engine details ...
Mahindra Max 25XL Power
Engine24 hp
17.9 kW
PTO (claimed)20 hp
14.9 kW
Mechanical
Four-wheel drive
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the Mahindra Max 25XL are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow4.6 gpm
17.4 lpm
Total flow7.3 gpm
27.6 lpm
Tractor hitch
Rear TypeI
Rear lift1354 lbs
614 kg
Power Take-off (PTO)
Rear PTOlive
Rear PTO Type540 (1.375)
Engine RPM540@2376
Mid PTO Type2000
Engine RPM2000@2556
Dimensions & Tires
Wheelbase58.2 inches
147 cm
Weight1715 lbs
777 kg
Front tire6x12
Rear tire9.5x16
Full dimensions and tires ...
Mahindra Max 25XL attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps50
Battery CCA450
Battery volts12
References
Max 25XL references literature
Max Series published in 2019, by Mahindra
