Kubota M1-100


Kubota M1-100 tractor photo
1988 - 1998
M1 Series
Utility tractor
Series:M1-85M1-100M1-115
Production
Manufacturer:Kubota
Type:Utility tractor
Kubota M1-100 Power
Engine:100 hp
74.6 kW
PTO (claimed):89.9 hp
67.0 kW
Kubota M1-100 Engine
Kubota 5.4L 5-cyl diesel
Fuel tank:39.6 gal
149.9 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Cab:Four-post ROPS. Cab optional.
Transmissions:24-speed
 36-speed creeper
Transmission details ...
Photos
No photos of the Kubota M1-100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS2
Rear lift:8157 lbs
3700 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2016
1000@2381
Dimensions & Tires
Wheelbase:101 inches
256 cm
Weight:8796 lbs
3989 kg
Front tire:13.6-24
Rear tire:16.9-38
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
