Tractors > Challenger > MT743

Challenger MT743

Challenger MT743 tractor photo
2018 -    MT700 Series
Agricultural Crawler tractor
Previous model:Challenger MT775E
Series back:Challenger MT740






Production:

Manufacturer:Challenger (a part of AGCO)
Factory:Jackson, Minnesota, USA


Challenger MT743 Engine:

   AGCO Power 9.8L 7-cyl diesel
full engine details ...


Capacity:

Fuel:180 gal [681.3 L]
 215 gal [813.8 L] *Optional
 257 gal [972.7 L] *Optional
Exhaust fluid (DEF):21 gal [79.5 L]


3-Point Hitch:

Rear Type:III/IVN
Rear lift:19000 lbs [8618 kg]


Dimensions & Tires:

Weight:33443 lbs [15169 kg]
full dimensions and tires ...


MT743 Serial Numbers:


how to read serial numbers...



Challenger MT743 Power:

Engine (gross):425 hp [316.9 kW]
PTO (claimed):334 hp [249.1 kW]


Mechanical:

Chassis:crawler
Cab:Cab standard with air-conditioning.


Hydraulics:

Type:load sensing
Valves:4 to 6
Pump flow:58 gpm [219.5 lpm]
 116 gpm [439.1 lpm] *With optional dual pumps.


Electrical:

Ground:negative
Charging system:alternator
