Kubota KL345 Transmission


Kubota KL345 tractor photo
2008 - 2009
KL Series
Compact Utility tractor
Series map:
KL315
KL345
KL385
22.8kw
25.0kw
27.9kw
Transmissions overview
16-speed
24-speed
Transmission
Gears16 forward and reverse
Four gears (1-4) in two ranges with additional creeper range and shuttle shift.
Speeds
KL345   speeds
Transmission
Gears24 forward and 16 reverse
Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.
