| 1999 - 2005 |
KL Series | Compact Utility tractor |
|
Transmissions overview |
20-speed |
30-speed |
Transmission |
Gears: | 20 forward and reverse
|
Four gears (1-4) in two ranges with three-range shift (creeper, medium, and high-speed). |
Speeds |
|
Transmission |
Gears: | 30 forward and 20 reverse
|
Twelve gears in three ranges (creeper, medium, and high-speed) with shuttle shift. Only gears 1-8 available in reverse. In high-speed range only gears six forward and four reverse gears available. |
